ATB/86 Fiber Optic Panel Empty Box

The ATB/86 Fiber Optic Panel Empty Box serves as a compact termination solution for FTTH networks. This 86mm standard wall-mounted enclosure supports fiber splicing and storage efficiently. Its empty design allows customization with adapters for seamless deployments.

Detailed Use Cases and Compatibility

Home Network Terminations

Homeowners install this panel for connecting indoor drop cables to routers. It organizes pigtails neatly behind wall outlets. Families access high-speed internet without visible clutter.

The flush-mount fits standard electrical boxes perfectly. It handles single-family fiber runs with minimal space. Upgrades from copper lines become straightforward.

Office and Small Business Setups

IT managers deploy it in conference rooms for endpoint connections. It terminates multiple drops to switches reliably. Teams maintain productivity with stable optical links.

Compatible with VoIP phones and IP cameras via fiber. The empty interior accommodates custom splice trays. Scalable for growing office bandwidth needs.

FTTH and Multi-Dwelling Units

Service providers use it in apartments for last-mile deliveries. It supports bulk cable entries from risers to units. Technicians splice on-site for quick activations.

The panel integrates with ONUs for XPON systems. It suits high-density housing with shared infrastructure. Ensures low-loss connections across floors.

For broader networking solutions, explore Aiconic Computers’ desktop computers category.

Rural and Outdoor Extensions

Installers apply it in remote cabins for outdoor cable protections. Weather-resistant seals guard against dust ingress. Farmers connect surveillance systems over fiber spans.

Pair with armored cables for harsh environments. The compact size mounts on poles or walls easily. Extends coverage to underserved areas effectively.

Cable and Adapter Compatibility

This box accepts G.652D single-mode fibers up to 3.1×2.0mm drops. It fits SC, LC, or DLC adapters for versatile terminations. Works with fusion splicers for low-attenuation joints.

Supports indoor and outdoor cables from φ8 to φ10.5mm. Compatible with RoHS-certified components for safety. Integrates with ODF systems for larger networks.

Learn FTTH standards from ITU’s fiber guidelines.

Technical Specifications

Construction and Dimensions

• Material: High-grade ABS or PC+ABS plastic
• Size: 86 x 86 x 25mm (standard wall plate)
• Color: White (custom options available)
• Mounting: Flush or surface on 86-type boxes

Capacity and Internal Layout

• Ports: 1-2 fiber terminations (empty, customizable)
• Splice Capacity: Up to 2 fusions with protector storage
• Cable Entry: 1 inlet for drop cable, 1-2 outlets for pigtails
• Adapter Slots: Supports SC simplex or LC duplex

Performance and Environmental

• Insertion Loss: ≤0.2dB at 1310/1550nm
• Return Loss: ≥50dB for APC connectors
• Operating Temperature: -25°C to +60°C
• Humidity: ≤85% at +30°C
• Protection: IP65 dust and water resistance

Certification and Durability

• Certifications: RoHS, CE, ISO
• Bend Radius Protection: ≥15mm internal routing
• Lifespan: 20 years under normal conditions
• Weight: 0.1 kg

Refer to IEEE’s optical networking resources for detailed fiber specs.

Trust-Building with Warranty and Support

Aiconic Computers ensures reliability in every fiber component we offer. The ATB/86 Fiber Optic Panel Empty Box includes a 12-month warranty against material defects. Our network specialists provide expert splicing consultations.

Free shipping applies to Nairobi orders with same-day pickup options. Online tutorials guide installations for DIY users. We stock adapters and tools for complete kits.

Serving thousands of installers across Kenya, our feedback highlights swift resolutions. Choose us for durable, standards-compliant gear that lasts.

For storage expansions, visit Aiconic Computers’ storage category.

Streamline Your Fiber Deployments

This empty panel reduces installation times with snap-on covers. Bend-insensitive routing prevents signal degradation. Cost-effective for bulk residential rollouts.

Combine with monitors for network monitoring stations. Aiconic Computers’ monitors category features compatible displays. Visualize connections clearly.

Recyclable materials support green initiatives. Low-profile design blends into interiors seamlessly. Versatility fits modern smart homes.

Fiber termination tips await at Lightwave’s FTTH guide.

Providers appreciate modular inserts for upgrades. Tamper-resistant latches secure urban installs. Performance holds in variable climates.

The intuitive layout aids novice technicians. Multi-language manuals enhance accessibility. Quality defines long-term network stability.

Enhance with projectors for training sessions. Aiconic Computers’ projectors category offers projection tools. Educate teams on best practices.

Precision-engineered slots minimize dust buildup. Future-proof for 10G+ speeds. Excellence powers every connection.
