Hikvision DS-1LN6AUSPE Outdoor Cat6A Cable

Hikvision DS-1LN6AUSPE Outdoor Cat6A Cable offers superior high-speed networking for challenging external environments. This advanced U/UTP Cat6A cable supports 10 Gigabit Ethernet performance. It ensures minimal crosstalk and reliable data transfer. Professionals rely on it for future-proof installations.

This cable withstands harsh outdoor conditions. It resists UV rays, moisture, and temperature fluctuations. The PE sheath provides long-lasting protection. Solid bare copper conductors deliver excellent conductivity. It supports extended PoE applications with low resistance. Use it for demanding networks that require higher bandwidth.

Detailed Use Cases and Compatibility

Hikvision DS-1LN6AUSPE Outdoor Cat6A Cable suits large-scale surveillance projects. Connect multiple high-resolution IP cameras over long distances. It handles 10 Gbps speeds for 4K and 8K video feeds. Deploy it in campus-wide systems, industrial parks, and smart city infrastructures. The cable powers PoE++ devices reliably outdoors.

Install it along building perimeters, through underground conduits, or exposed to sunlight. It works with advanced network switches, routers, and access points. The design reduces alien crosstalk in bundled runs. Pair it with Hikvision NVRs and third-party Cat6A equipment. It supports structured cabling in schools, hospitals, and commercial complexes. The cable maintains performance in wet or sunny climates.

For more reliable networking gear, visit Aiconic Computers. Check our desktop computers to support high-bandwidth control stations.

Technical Specifications

General

• Model: DS-1LN6AUSPE(O-STD)
• Category: Cat.6A
• Structure: U/UTP (Unshielded Twisted Pair)
• Usage Scenario: Outdoor
• Fire Resistance: CPR Fca
• Cable Length: 305 ± 1.5 m
• Outer Jacket Color: Black
• Rip-cord: Yes
• Separator: Yes

Conductor

• Material: Solid-Bare Copper (99.95% purity)
• Diameter: 0.565 ± 0.005 mm (23 AWG)

Insulation

• Material: HDPE
• Diameter: 1.12 ± 0.1 mm

Outer Sheath

• Material: Polyethylene (PE) – UV and weather resistant
• Sheath Color: Black

Performance Highlights

• Compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801, RoHS 2.0
• Excellent alien crosstalk performance (6-around-1 test)
• Supports 10 Gbps Ethernet up to 100 m
• Stable impedance and low delay skew
• Verified Fluke testing for high-frequency performance
• Superior PoE support with reduced resistance

Environmental

• Operating Temperature: –20 °C to +75 °C
• Maximum Operating Voltage: 57 V

Enhance your setup with options from our monitors collection.

Trust-Building with Warranty and Support

Aiconic Computers delivers authentic Hikvision solutions across Kenya. This cable includes manufacturer quality assurance. It passes strict international testing for durability and performance. Our team provides expert installation advice. We offer prompt nationwide delivery. Contact us for ongoing technical assistance. Invest in this cable for dependable, long-term outdoor connectivity.

Explore cabling standards at TIA Online. Review international guidelines from ISO. Learn about certification from Fluke Networks.
