Hikvision DS-3E1510P-SI Smart Managed Gigabit PoE SI Series

Hikvision DS-3E1510P-SI Smart Managed Gigabit PoE SI Series delivers reliable power and data connectivity for IP surveillance networks. This switch combines 8 Gigabit PoE ports with 2 Gigabit fiber uplinks. It powers cameras and devices efficiently. Installations in Nairobi and Kenya benefit from stable performance. Security teams deploy cameras without extra power sources. Network managers monitor health remotely. The switch simplifies maintenance and expansion.

The device supports IEEE 802.3at/af standards. It provides up to 110 W total PoE budget. Smart features include topology visualization and alarm notifications. Extend mode reaches up to 300 m for remote cameras. PoE watchdog restarts unresponsive devices automatically. Layer 2 protocols ensure network stability.

Use Cases and Compatibility

This switch suits IP camera deployments in various settings. In commercial buildings, power and connect multiple HD cameras. Retail stores use it for point-of-sale and surveillance integration. Residential complexes secure perimeters with long-range PoE. Small offices manage VoIP phones alongside cameras.

The DS-3E1510P-SI features 8 Gigabit PoE RJ45 ports and 2 Gigabit SFP fiber ports. It supports IEEE 802.3af/at for PoE+ devices. Connect Hikvision IP cameras, NVRs, and access points. Use SFP modules for fiber uplinks to core switches. Enable long-distance transmission in extend mode. Manage via web interface or Hik-Partner Pro platform.

Support STP/RSTP for loop prevention. Implement VLANs for traffic segmentation. Apply QoS for video priority. Use link aggregation for higher bandwidth. Monitor network topology and receive real-time alarms. Integrate with Hikvision software for centralized control. Work in standard or extend modes. Suit indoor rack or desktop mounting.

For quality networking in Kenya, visit Aiconic Computers. Browse monitors for control room setups.

Technical Specifications

Network Parameters

• Ports: 8 × Gigabit PoE ports, 2 × Gigabit SFP fiber ports
• Port Type: RJ45 full duplex, MDI/MDI-X adaptive
• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
• Switching Capacity: 20 Gbps
• Packet Forwarding Rate: 14.88 Mpps
• MAC Address Table: 8 K
• Internal Cache: 4.1 Mbits

PoE Power Supply

• PoE Standard: IEEE 802.3af, IEEE 802.3at
• PoE Power Pin: End-span: 1/2(-), 3/6(+); Mid-span: 4/5(+), 7/8(-); 8-pin: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
• Max. Port Power: 30 W per port (ports 1 to 8)
• PoE Power Budget: 110 W
• Long Range: Up to 300 m in extend mode

General

• Shell: Metal material, fanless design
• Surge Protection: 6 kV
• Power Supply: 48 VDC, 2.5 A
• Power Consumption: Max. 120 W, Idle 7 W
• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
• Operating Humidity: 5% to 95% (non-condensing)
• Dimensions: 217.60 mm × 27.80 mm × 108.55 mm (8.57″ × 1.09″ × 4.27″)
• Net Weight: 1.21 kg (2.67 lb)

Key Features

• Network topology management and health monitoring
• Real-time alarm push notifications
• PoE watchdog for automatic device restart
• Supports STP/RSTP, VLAN, link aggregation, SNMP, QoS
• One-click activation via Hik-Partner Pro

The switch uses passive cooling for silent operation. It withstands surges effectively. Easy web management reduces maintenance time.

Explore desktop computers at Aiconic Computers for network management.

Reliable Performance and Support

Aiconic Computers supplies authentic Hikvision networking products to Kenyan clients. The Hikvision DS-3E1510P-SI Smart Managed Gigabit PoE SI Series includes a manufacturer warranty against defects. Our Nairobi team provides expert support. Receive guidance on installation, configuration, PoE setup, and troubleshooting. Access firmware updates promptly. Trust our experience for robust IP surveillance networks.

Refer to Hikvision’s network switches overview here, smart managed series here, and networking guidelines here.
