Hikvision DS-K1201AMF Fingerprint Card Reader combines MIFARE 1 card reading with advanced optical fingerprint technology. This robust device stores up to 5000 fingerprints securely. It supports multiple authentication modes for enhanced access control. The reader uses Hikvision private RS-485 protocol. IP65 rating ensures outdoor durability in Kenya. It provides fast and accurate verification. Tamper-proof design protects against sabotage.

Use Cases and Compatibility

Hikvision DS-K1201AMF Fingerprint Card Reader fits offices, residential estates, schools, hospitals, hotels, and industrial sites. It secures doors with biometric and card options. Use fingerprint alone for quick entry. Combine card and fingerprint for high-security needs. The device reads MIFARE 1 cards at distances from 30 mm to 100 mm.

This reader integrates with Hikvision access controllers via RS-485. It supports 19200bps transmission with CRC checks. Multiple modes include card only, fingerprint only, and card plus fingerprint. Optical CMOS module exports fingerprint data reliably. It handles 1:1 and 1:N comparisons efficiently. FRR stays below 0.01%. FAR remains under 0.001%.

The IP65 protection resists dust and water. It operates from -40°C to 70°C. This broad range suits Kenya’s climates. Coastal humidity and highland variations cause no issues. Surface mounting fits standard frames. Built-in buzzer indicates status clearly.

Discover compatible access controllers in our desktop computers category.

Technical Specifications

Hikvision DS-K1201AMF Fingerprint Card Reader meets strict performance standards. Key specifications include:

• Fingerprint Capacity — 5000
• Fingerprint Module — Optical CMOS
• Fingerprint Comparison Modes — 1:1 / 1:N
• Card Type — MIFARE 1 (M1) card
• Card Induction Distance — 30 mm to 100 mm
• Authentication Modes — Card, fingerprint, card + fingerprint
• Communication — RS-485 (Hikvision private, 19200bps-N-8-1, CRC check)
• Power Supply — 12 VDC ± 10%
• Power Consumption — ≤ 1.6 W
• Working Temperature — -40°C to 70°C (-40°F to 158°F)
• Working Humidity — 10% to 90% (non-condensing)
• Protection Level — IP65
• Dimensions — 62 mm × 132 mm × 44 mm (2.44″ × 5.20″ × 1.73″)
• Additional Features — Tamper-proof function, built-in buzzer, encrypted fingerprint storage, optical coupling isolation

The device ensures secure, encrypted fingerprint data. It supports fast comparison times.

Learn about biometric standards from the Door and Hardware Institute. It covers fingerprint module requirements.

Benefits of Choosing This Fingerprint Card Reader

This reader delivers multi-factor security options. Biometric fingerprint adds convenience and accuracy. Encrypted storage protects user data. IP65 rating allows outdoor placement. Low power consumption reduces costs. Tamper-proof feature deters attacks. Multiple modes fit different security levels. Wide temperature range suits local conditions. Fast verification improves user experience. Overall, it provides reliable, advanced access control.

Trust-Building: Warranty and Support

Aiconic Computers supplies genuine Hikvision DS-K1201AMF Fingerprint Card Reader units. We include full manufacturer warranty. Hikvision offers dependable support for this device. Customers receive expert help on installation and configuration.

Our Nairobi team responds quickly to questions. We provide fast delivery across Kenya. Trust our service for lasting satisfaction. The durable IP65 design promises years of reliable performance. Many installations operate flawlessly over extended periods.

Explore more biometric options in our monitors category.

Consult British Standards Institution for access control guidelines.

Shop confidently at Aiconic Computers. We prioritize quality and customer care.
