Hikvision DS-K1T502DBFWX-C Access Control Terminal

Hikvision DS-K1T502DBFWX-C Access Control Terminal combines advanced access control, video intercom, and high-capacity biometric verification into one professional-grade security solution perfect for demanding Kenyan environments.

Modern businesses, residential estates, industrial facilities, and commercial complexes across Nairobi increasingly require integrated devices that handle multiple security functions without compromising performance or reliability. This terminal meets those needs by offering fingerprint recognition, card reading, PIN entry, two-way video communication, and robust event logging—all protected by an IP65 and IK09-rated zinc alloy enclosure.

Whether securing main entrances, controlling restricted zones, or managing visitor flow, the Hikvision DS-K1T502DBFWX-C Access Control Terminal delivers fast, contactless, and traceable access while supporting remote management through mobile applications.

Key Features of Hikvision DS-K1T502DBFWX-C Access Control Terminal

Provide multi-factor authentication options. Enable seamless video intercom. Store massive user and event databases. Withstand harsh weather and physical impact.

Detailed Use Cases and Compatibility

Corporate headquarters deploy the terminal at lobby entrances and executive floors to restrict unauthorized movement while allowing quick employee access via fingerprint or card. Gated residential communities use it at vehicle and pedestrian gates, combining facial or card verification with live video intercom for visitors. Manufacturing plants install units at production-area doors to log shift attendance and prevent tailgating.

Financial institutions apply it in teller zones and vaults for layered security. Retail chains secure cash offices and stockrooms. Educational campuses control lecture halls and laboratories. The device operates effectively in both standalone mode for small sites and fully networked mode for multi-location enterprises.

It supports SIP 2.0 video intercom protocol, allowing connection to indoor stations, management centers, or the Hik-Connect mobile app. Bluetooth enables mobile credential unlocking. RS-485 and Wiegand interfaces facilitate integration with third-party controllers and external card readers. Standard alarm inputs/outputs connect to intrusion sensors, while door contact and exit button terminals link directly to electromagnetic locks.

For centralized administration of multiple terminals, pair the system with powerful management workstations. Browse compatible desktop computers at Aiconic Computers.

Technical Specifications

• Operating System: Linux
• CPU: 960 MHz high-performance processor
• Display: Not applicable (functional interface via client/software)
• Camera: 1 × 2 MP wide-angle lens
• Field of View: Horizontal 110°, Vertical 81°, Diagonal 122°
• Video Compression: H.264 / H.265
• Fingerprint Capacity: 10,000 (capacitive module)
• Card Capacity: 100,000 (M1 & DESFire EV1/EV2 compatible)
• Event Capacity: 300,000 records (expandable via SD card up to 256 GB)
• Authentication Methods: Capacitive fingerprint, M1/DESFire card, PIN, combinations
• Card Reading Distance: 0–3 cm
• Network Interface: 10/100 Mbps self-adaptive Ethernet (RJ-45)
• Wireless: Wi-Fi 2.4 GHz (IEEE 802.11b/g/n), Bluetooth
• Communication Protocols: TCP/IP, SIP 2.0, ISAPI, OSDP
• Interfaces: • 1 × Lock relay output • 1 × Exit button input • 1 × Door contact input • 1 × Alarm input • 1 × Alarm output • 1 × Tamper • 1 × RS-485 (half-duplex, HIKVISION protocol) • 1 × Wiegand output (26/34 bit) • 1 × USB • 1 × SD card slot (≤ 256 GB)
• Power Supply: 12–24 VDC, 1 A
• Power Consumption: ≤ 12 W
• Operating Temperature: –40 °C to +70 °C
• Operating Humidity: 0%–90% (non-condensing)
• Protection Rating: IP65 (dust-tight & water-resistant), IK09 (high impact resistance)
• Material: Zinc alloy front panel
• Additional Features: Live view streaming, two-way audio, anti-spoofing protection, Hik-Connect mobile management

These specifications guarantee dependable operation even during power fluctuations or extreme weather conditions common in Kenya.

Explore cutting-edge security technology standards directly from the Hikvision official site (high-authority manufacturer resource).

Why Choose Aiconic Computers

Aiconic Computers has established itself as one of Kenya’s most trusted Hikvision partners. We import and distribute only genuine, factory-sealed products accompanied by the full manufacturer warranty. Before dispatch, every terminal undergoes meticulous quality inspection to ensure flawless performance upon arrival.

Our dedicated technical support team assists with on-site installation, network configuration, SIP integration, and mobile app setup. We remain available for troubleshooting and firmware updates long after purchase. Extended warranty and maintenance packages further increase peace of mind for medium-to-large deployments.

Shop locally and confidently. Visit our complete product catalog at https://www.aiconiccomputers.co.ke/.

For comprehensive monitoring stations, browse our selection of professional-grade monitors.

Keep informed about global trends in biometric access control and physical security from Biometric Update – an independent, highly respected industry authority.

Invest in the Hikvision DS-K1T502DBFWX-C Access Control Terminal today. Combine convenience, security, and scalability for your organization’s future.
