Siemon Cat 6 Cable

Siemon Cat 6 Cable delivers premium performance for structured indoor networking installations. This high-quality 305-meter reel supports full Gigabit Ethernet reliably. It exceeds industry standards with exceptional headroom. Professionals choose it for demanding enterprise and commercial projects.

Rely on Aiconic Computers for authentic Siemon products. Discover compatible desktop computers to build complete high-performance systems.

Detailed Use Cases for Siemon Cat 6 Cable

Enterprise offices install this cable for horizontal and backbone cabling. Employees transfer large files efficiently. Video conferencing maintains high quality without drops. The superior headroom minimizes errors in dense environments.

Data centers use it for server-to-switch connections. It supports reliable 1000BASE-T links. Network administrators achieve consistent performance across racks. The cable handles high port density effectively.

Educational institutions wire classrooms and labs. Students access online resources smoothly. Faculty deliver digital content without interruptions. The design suits multi-user setups.

Healthcare facilities connect workstations and imaging systems. Staff retrieve records quickly. Diagnostic data transmits accurately. Pure copper construction ensures signal integrity.

Smart buildings deploy it for integrated systems. IoT devices connect stably. Building management operates reliably. The cable supports future-proof upgrades.

Installers benefit from the center isolation member. It maintains pair geometry during pulls. Reelex or pull-box packaging eases deployment. Sequential markings reduce waste.

Combine with Siemon connectivity for end-to-end channels. Integrate with POS in retail networks. Pair with projectors for conference setups.

Backward compatibility includes Cat 5e networks. It exceeds requirements for lower categories. Standard RJ45 termination works seamlessly.

Use indoors in controlled environments. Select appropriate jacket variants for specific needs.

Technical Specifications

Cable Construction

Category: Cat 6 Unshielded Twisted Pair (UTP) Conductor Material: 100% Pure Bare Copper Conductor Gauge: 23 AWG solid (0.57 mm nominal) Number of Pairs: 4 twisted pairs Insulation: Polyethylene (PE) or FEP (variant dependent) Separator: Center isolation member for pair geometry Rip Cord: Applied longitudinally under jacket

Performance Characteristics

Frequency Range: Up to 250 MHz (with significant headroom) Maximum Data Rate: 1 Gbps (1000Base-T) over 100 meters Compliance: Exceeds ANSI/TIA-568.2-E Category 6, ISO/IEC 11801-1 Class E, IEC 61156-5 Key Parameters (typical for System 6):

• Return Loss: Superior to standard requirements
• NEXT: High margin above specifications
• PSNEXT: Exceptional performance
• Attenuation: Low for reliable long runs
• Delay Skew: ≤35 ns/100m

Physical and Environmental Properties

Outer Jacket: PVC (CM/CMR) or LSOH variants, various colors available Jacket Nominal O.D.: Approximately 5.84–6.1 mm (variant dependent) Bend Radius: 4× diameter (installation), 8× (operating) Operating Temperature: -20°C to 60°C (typical) Installation Temperature: 0°C to 50°C Length per Reel: 305 meters (1000 feet) Reelex or box Packaging: Reelex II or pull-out box with sequential markings Weight: Approximately 13–15 kg per reel Flame Rating: CM, CMR, or LSOH options

Additional Features

PoE Compatibility: Supports IEEE 802.3af/at/bt (PoE++) Connector Compatibility: Standard RJ45 (T568A/B) Lead-Free Jacket: Compliant materials Performance Verification: UL verified in many variants

Pure copper conductors ensure low DC resistance. They provide excellent PoE support and minimal attenuation. The isolation member optimizes crosstalk performance.

Why Choose Aiconic Computers for Siemon Cat 6 Cable

Aiconic Computers supplies genuine Siemon cabling solutions. We offer manufacturer-backed quality assurances. This cable includes performance warranty coverage from the manufacturer.

Our team provides expert installation guidance. We assist with termination and testing recommendations. Compatibility inquiries receive prompt responses. Service ensures efficient supply.

Support continues post-purchase. We help with network optimization. Visit our homepage at Aiconic Computers for more resources.

We prioritize reliability and customer trust. Bulk orders qualify for competitive pricing.

Explore Category 6 standards on TIA Online. Learn pure copper benefits at Belden Resources. Review best practices via Cisco Networking.

Superior Category 6 Performance

Siemon Cat 6 Cable combines exceptional engineering with reliable durability. It exceeds Gigabit requirements with headroom. The premium construction ensures long-term stability.

Invest in this cable for professional networks. It delivers consistent high-speed connectivity. Order now to elevate your infrastructure.
