Easenet Indoor Copper UTP Cat 6

Easenet Indoor Copper UTP Cat 6 delivers high-quality pure copper cabling for superior indoor networking. This 305-meter cable supports full Gigabit Ethernet performance reliably. It ensures excellent signal integrity and longevity. Professionals choose it for demanding structured installations.

Rely on Aiconic Computers for genuine networking products. Discover compatible desktop computers to build complete systems.

Detailed Use Cases for Easenet Indoor Copper UTP Cat 6

Corporate offices install this cable for backbone and horizontal runs. Employees transfer large datasets quickly. Video conferences maintain clear audio and video. The pure copper design minimizes packet loss.

Government buildings wire secure networks. Departments connect workstations to central servers. Data remains protected with stable links. The cable handles high-density port environments effectively.

Hotels equip guest rooms and conference areas. Guests enjoy fast internet access. Management systems operate without interruptions. The cable supports multiple simultaneous connections.

Hospitals run it to diagnostic stations and admin offices. Medical staff access patient records instantly. Imaging files transmit rapidly. Pure copper ensures consistent performance.

Universities deploy it across faculties and dorms. Students connect laptops and devices reliably. Research labs process complex computations. The cable exceeds standard requirements.

Installers appreciate the flexible yet durable PVC jacket. Routing through conduits and trays becomes straightforward. The pull-box format eases deployment in large projects.

Combine with managed switches for advanced configurations. Integrate with POS terminals in commercial settings. Pair with projectors for presentation networks.

Backward compatibility includes Cat 5e and Cat 5 equipment. Upgrade paths support future 10 Gigabit short runs. It fits all standard RJ45 interfaces.

Use exclusively indoors in dry conditions. Avoid outdoor or plenum spaces unless specified.

Technical Specifications

Cable Construction

Category: Cat 6 Unshielded Twisted Pair (UTP) Conductor Material: 100% Pure Bare Copper Conductor Gauge: 23 AWG Number of Pairs: 4 twisted pairs Insulation: High-Density Polyethylene (HDPE) Separator: Cross-web spline for pair isolation Rip Cord: Yes, for easy jacket access

Performance Characteristics

Frequency Range: Up to 250 MHz Maximum Data Rate: 1 Gbps (1000Base-T) over 100 meters; supports 10 Gbps over shorter distances Compliance: Exceeds TIA/EIA-568-C.2 Category 6 standards for permanent links Key Parameters:

• Return Loss: ≥20.1 dB @ 100 MHz
• NEXT: ≥39.3 dB @ 100 MHz
• PSNEXT: ≥37.1 dB @ 100 MHz
• ACR-F: ≥23.3 dB @ 100 MHz
• Attenuation: ≤22.0 dB/100m @ 100 MHz

Physical and Environmental Properties

Outer Jacket: Flame-retardant PVC (CM rated), typically grey or blue Jacket Thickness: Optimized for flexibility and protection Cable Diameter: Approximately 6.0–6.5 mm Bend Radius: 4× diameter (installation), 8× (operating) Operating Temperature: -20°C to 60°C Installation Temperature: 0°C to 50°C Length per Reel: 305 meters (1000 feet) Packaging: Pull-out box with sequential meter markings Weight: Approximately 13–15 kg per reel

Additional Features

PoE Support: Compatible with IEEE 802.3af/at/bt (PoE++) due to low DC resistance Connector Compatibility: Standard RJ45 (T568A/B wiring) Flame Rating: CM for general indoor use Low Smoke: Non-LSZH (check batch for variants)

Pure copper conductors provide superior conductivity. They support longer PoE distances reliably. The cable maintains performance in EMI-prone areas.

Why Choose Aiconic Computers for Easenet Indoor Copper UTP Cat 6

Aiconic Computers offers authentic Easenet products. We provide manufacturer-backed quality guarantees. This cable includes performance warranty coverage from the manufacturer.

Our team delivers expert technical advice. We guide on proper termination and testing. Compatibility concerns receive immediate attention. Service ensures quick supply.

Support persists after delivery. We assist with network certification and optimization. Visit our homepage at Aiconic Computers for additional resources.

We focus on customer trust and product excellence. Bulk orders qualify for competitive pricing.

Understand Cat 6 standards via TIA Online. Compare pure copper benefits at Belden Resources. Review installation practices on Cisco Networking.

Premium Indoor Networking Cable

Easenet Indoor Copper UTP Cat 6 combines quality construction with reliable performance. It meets rigorous Gigabit requirements indoors. The durable design ensures years of service.

Invest in this cable for professional networks. It delivers consistent, high-speed connectivity. Order now to strengthen your infrastructure.
